Application Scope: The YW27 series single-action thin plate drawing hydraulic press is specially used for stretching, bending and forming processes of sheet metal. It can also be used for blanking, correction, press-fitting and punching, suitable for industries such as automotive, aviation and chemical engineering.
Technical Advantages:

Adopts reverse stretching process; the hydraulic cushion can be installed inside or outside the workbench.

Hydraulic system uses cartridge valves; electrical system is automatically controlled by PLC, supporting jog and semi-automatic operation modes.

The stroke, pressure and speed of each moving part can be adjusted independently within a certain range to meet different process requirements.

Optional Accessories
Blanking buffer
Mobile workbench
Light screen safety device
Oil cooling device
Industrial touch screen
Ejector device
Rapid clamping mechanism for mould
Floating guide rail and rolling bracket for changing mould

Parameter Name	Unit	YW27-63	YW27-100	YW27-160	YW27-200	YW27-315	YW27-500	YW27-630	YW27-1250	YW27-1600
Nominal Force	kN	630	1000	1600	2000	3150	5000	6300	12500	16000
Hydraulic Cushion Force	kN	190	400	400	630	1000	1600	2000	4000	4000
Max Working Pressure of Liquid	MPa	25	25	25	25	25	25	25	25	25
Slide Stroke	mm	500	600	700	700	800	900	900	1200	1200
Hydraulic Pad Max Stroke	mm	200	200	250	250	300	350	350	400	400
Opening Height	mm	1000	1000	1000	1100	1250	1500	1500	1800	1800
Slide Speed - Downward	mm/s	150-180	150-180	100	100	100	100	100	150-200	150-200
Slide Speed - Working	mm/s	20-25	10-14	10-15	12-18	8-12	10-15	8-12	15-20	10-12
Slide Speed - Return	mm/s	60	120	70	70	60	70	60	100	120
Working Table Size (Front/Back)	mm	580	720	960	920	1150	1400	1500	3800	3500
Working Table Size (Left/Right)	mm	500	580	800	900	1200	1400	1500	2200	2200
Machine Dimension (Front/Back)	mm	380	450	600	660	700	1000	850	3100	2800
Machine Dimension (Left/Right)	mm	380	450	600	660	700	1000	850	1600	1600
Total Motor Power	kW	7.5	7.5	11	15	22	2X22	2X22	4X37	4X55
