CH-65120 Gantry Column Structure Horizontal Straight Cutting Bandsaws

Product Overview: MFG CH-65120

The MFG CH-65120 Gantry Metal Band Saw is specifically engineered to deliver flawless, high-efficiency straight cuts for medium to extra-large metalworking applications.

Constructed with a premium gantry-style framework featuring generous structural margins, the CH-65120 ensures absolute stability and vibration dampening during intense operations. Whether processing solid ferrous blocks or large non-ferrous metal plates, this machine provides an unparalleled balance of rapid cutting speeds, reduced kerf loss, and exceptional straight-cut accuracy. It is the ultimate asset for heavy industrial facilities looking to boost throughput while conserving energy and raw material.

Engineered for Excellence: Key Features

• Dual-Column Gantry Rigidity: The heavy-duty gantry structure is guided by high-precision linear rails, eliminating blade deflection to guarantee strictly accurate straight sawing.
• Synchronized Hydraulic Feeding: Driven by an advanced double oil cylinder system, the machine maintains a remarkably stable and uniform downfeed rate, even through the most resistant metals.
• Automated Material Handling: Paired with a hydraulically controlled vise clamping system, the motorized infeed and receiving roller tables make handling massive workpieces seamless and labor-saving.
• Smooth Power Transmission: The core drive mechanism features an industrial-grade bevel helical gear reducer. This guarantees a smooth, impact-free power transfer that maximizes transmission efficiency and prolongs equipment life.
• Optimized Blade Control: Equipped with a hydraulic saw belt tensioner and an automatic broken-belt safety mechanism. Cutting speeds are easily adjustable via the integrated frequency conversion (VFD) controls.
• Modular Hydraulic Station: The hydraulic system operates from a standalone, independent unit, ensuring consistent fluid pressure and making routine maintenance highly accessible.
• (Optional): A motorized chip cleaning device can be integrated to automatically clear swarf and maintain peak cutting performance.

Core System Components

Every MFG CH-65120 is built with the following industrial-grade assemblies:

• Reinforced Machine Base
• High-Efficiency Main Drive System
• Hydraulic Vise Clamping Mechanism
• Rigid Saw Frame/Bow
• Precision Linear Guiding Device
• Hydraulic Blade Tensioner & Safety System
• Industrial Cooling/Lubrication System
• Independent Hydraulic Power Unit
• Centralized Electrical Control System
