CH-1500 Gantry Column Structure Horizontal Straight Cutting Bandsaws

Product Overview: CH-1500 Heavy-Capacity Gantry Saw

Built specifically to conquer oversized industrial materials, the CH-1500 Gantry Metal Band Saw delivers uncompromising performance for heavy-duty straight cutting applications.

By utilizing an ultra-rigid gantry architecture with generous structural margins, this machine guarantees absolute stability and vibration reduction, even when processing massive ferrous and non-ferrous bars or plates. It is meticulously engineered to provide large-scale manufacturing facilities with a highly efficient, energy-saving solution that minimizes kerf waste while maximizing daily throughput and straight-cut precision.

Operational Advantages

• Ultra-Rigid Gantry Framework: The foundational gantry structure is paired with top-tier linear guide rails, effectively eliminating mechanical deflection and ensuring flawless, high-precision straight sawing.
• Twin-Cylinder Downfeed Control: Engineered with a dual hydraulic cylinder system, the CH-1500 guarantees a highly stable, uniform cutting feed rate through even the toughest metal blocks.
• Powered Material Handling: Heavy workpiece manipulation is streamlined through motorized infeed and outfeed roller tables, working seamlessly with the hydraulic vise clamping system for secure, automated operation.
• Intelligent Blade Management: Maximize your saw band's lifespan with the hydraulic blade tensioning system and built-in broken belt protection. The cutting speed is fully adjustable via Variable Frequency Drive (VFD) to match specific material hardness.
• High-Efficiency Transmission: The primary drive utilizes a heavy-duty bevel helical gear reducer. This configuration ensures an impact-free, smooth power transfer, resulting in superior energy efficiency and long-term durability.
• Centralized Independent Hydraulics: Designed with an independent hydraulic power station, keeping the fluid systems isolated for improved safety, consistent pressure, and highly convenient routine maintenance.
• (Optional): An automated chip conveyor/cleaning device is available to handle the high volume of swarf generated by large-scale cutting.

Equipment Configuration

The CH-1500 is systematically assembled with industrial-grade modules:

• Heavy-Duty Machine Base
• Primary Drive Gearbox System
• Hydraulic Vise Clamping Assembly
• Reinforced Saw Bow/Frame
• Precision Linear Guiding Mechanism
• Hydraulic Tensioner & Safety Protection Device
• Industrial Coolant Circulation Setup
• Standalone Hydraulic Power Station
• Integrated Electrical Control Panel
