CH-1200 Gantry Column Structure Horizontal Straight Cutting Bandsaws

Product Introduction

Engineered for demanding industrial applications, this Industrial-Grade Gantry Metal Band Saw CH-1200 is the ideal solution for processing medium to large-scale ferrous and non-ferrous materials.

Unlike standard saws, this machine utilizes a reinforced gantry-style framework that guarantees exceptional structural integrity and vibration-free performance. Whether you are cutting solid steel bars or thick metal plates, this equipment delivers an optimal balance of rapid cutting speeds, reduced kerf loss (saving you valuable material costs), and energy-efficient operation. It is built to maximize your daily production capacity while keeping operating costs low.

Core Advantages & Capabilities

• Reinforced Gantry Architecture: The heavy-duty gantry design, paired with premium linear guide rails, eliminates deflection and ensures industry-leading sawing accuracy.
• Seamless Material Handling: Handling heavy workpieces is effortless thanks to the integrated motorized infeed and outfeed roller tables. The dual hydraulic cylinder system guarantees a consistently smooth and stable down-feed.
• Advanced VFD & Blade Protection: Take full control of your cutting parameters with the Variable Frequency Drive (VFD) for adjustable cutting speeds. The integrated hydraulic blade tensioning system—complete with automatic broken-belt protection—significantly extends the lifespan of your saw blades.
• Shock-Free Power Transmission: The main drive system is powered by a high-torque bevel helical gear reducer. This provides smooth, impact-free energy transfer, resulting in higher transmission efficiency and a longer service life.
• Accessible Hydraulic Control: Features an independent hydraulic station that securely powers both the vise clamping and the sawing feed. Its standalone design makes routine maintenance and servicing quick and hassle-free.
• (Optional Upgrade): An automatic chip cleaning device can be added to maintain a clean cutting environment and further reduce manual labor.

Standard System Components

Every unit is strictly assembled with the following high-quality modules:

• Rigid Machine Base & Structural Frame
• Heavy-Duty Saw Bow/Frame
• Primary Drive Mechanism
• Precision Blade Guiding Assembly
• Hydraulic Vise Clamping System
• Hydraulic Tensioner & Belt-Break Safety Device
• Industrial Coolant Circulation System
• Standalone Hydraulic Power Unit
• Centralized Electrical Control Cabinet
