| Model | unit | DP20013b (e813b) | DP25013b/25016b (1013b/1016b) | DP30013b/30016b (1213b/1216b) | DP34016b/f (1316b/1316f) |
|---|
| max.drilling capacity | mm | 13 | 13/16 | 13/16 | 16 |
| diameter of column | mm | 46 | 60 | 60 | 73 |
| spindle travel | mm | 50 | 60 | 60 | 80 |
| distance spindle axis to column generating line | mm | 103 | 127 | 152.4 | 168.5 |
| max. distance spindle nose to table | mm | 220 | 290/300 | 395/405 | 435/770 |
| max. distance spindle nose to base | mm | 300 | 410/420 | 520/530 | 680/1250 |
| spindle taper | - | jt33 or b16 | jt33/mt2 | jt33/mt2 | mt2 |
| spindle speeds range | r/min | 515~2580 | 515~2580 | 515~2580 or 180~2740 | 180~2740 |
| spindle speeds series | - | 5 | 5 | 5 or 12 | 12 |
| dimension of table surface | mm | 160 x 160 | 200 x 200 | 220 x 220 | 254 x 254 or Φ300 |
| dimension of base | mm | 280 x 185 | 345 x 210 | 400 x 250 | 460 x 270 |
| overall height | mm | 580 | 720 | 820 | 1020/1600 |
| power of motor | w | 125(1/6hp) or 180(1/4hp) | 180(1/4hp) or 250(1/3hp) | 180(1/4hp) or 250(1/3hp) | 370(1/2hp) |
| g.w/n.w | kg | 21/19 | 33/30 | 34/31 | bench:57/52floor:62/57 |
| packing dimension | cm | 45 x 33 x 23 or 45 x 36 x 23 | 57 x 38 x 24 | 67 x 45 x 28 | b:88 x 48 x 28f:140 x 50 x 24 |
| units per 1 x 20' container | - | 820 | 540 | 330 | 220/160 |
