High-Rigidity Steel Plate Welded Frame: The machine body is constructed with steel plate welding, ensuring excellent structural rigidity and stability during high-load operations.
Overload Protection System: Equipped with a highly responsive and reliable overload protection device. It safeguards both the mold and the machine tool, allowing for quick recovery and minimal downtime in case of overload.
PLC-Controlled Electrical System: The press adopts PLC-based electrical control for consistent, reliable, and stable operation.
Enclosed Gear Drive with Oil Immersion Lubrication: Features enclosed gear transmission with oil bath lubrication, ensuring smooth power delivery, low noise levels, and long service life of key components.
Modular Pneumatic Clutch-Brake Assembly: Utilizes a combined pneumatic clutch-brake unit with imported friction materials, delivering long service life, high safety, and precise response.

No.	Description	Quantity
1	Hydraulic Overload Protection Device	1 Set
2	Electric Slide Adjustment Device	1 Set
3	Electric Grease Lubrication Device	1 Set
4	Slide and Mold Balancing Device	1 Set
5	Electronic Cam (PAC10) Controller	1 Set
6	Pointer Type Crankshaft Angle Indicator	1 Unit
7	Digital Mold Height Indicator (0.1mm)	1 Unit
8	Constant Speed Motor	1 Set
9	Programmable Controller PLC	1 Set
10	Maintenance Tools and Toolbox	1 Set
11	Operation Manual and Inspection Certificate (Chinese Version)	1 Copy

No.	Description	Quantity
1	Manual Grease Lubrication Device	1 Set
2	Main Motor Reversing Device	1 Set
3	Upper Slide Material Device [Slide Knockout Rod]	1 Set
4	Preset Counter (6 Digits)	1 Set
5	Maintenance Hour Timer	1 Set
6	Photoelectric Safety Device	1 Set
7	Shockproof Device S78-10-06	1 Set
8	Quick Die Change Device (see attached drawing for details)	1 Set
9	Air Cushion Device Without Tank	1 Set
10	Secondary Drop Protection Device	1 Set
11	Safety Fence	1 Set

Type [Model]	25 T	45 T	63 T	80 T	125 T	160 T	200 T	250 T	315 T	400 T
Nominal Force (kN)	250	450	630	800	1250	1600	2000	2500	3150	4000
Ability Occurrence Point (mm)	3	4	4	5	5	6	6	8	8	10
Slide Stroke (mm)	80	100	120	140	160	180	200	200	200	200
Max Die Set Height (mm)	250	270	300	320	370	400	450	450	430	430
Number of Strokes of Slider (times/min)	100	80	70	60	50	45	40	40	30	25
Mold Height Adjustment (mm)	50	60	80	80	100	110	110	110	120	120
Throat Depth (mm)	210	230	300	300	370	390	430	450	420	420
Slider Surface Size (mm)	250×360	340×410	400×480	420×560	520×620	580×700	650×880	700×930	650×850	650×850
Bed Dimension (mm)	700 × 400	810 × 440	900 × 580	1000 × 580	1120 × 720	1200 × 760	1400 × 840	1500 × 880	1400 × 800	1400 × 800
Main Motor (kW)	3×4	5.5×6	5.5×6	7.5×4	11×4	15×6	18.5×6	22×6	30×6	37×6
