MFG Machinery CK5120 CNC Vertical Turning Lathe (VTL)

2000mm Swing, 30kW Servo Drive & Square Ram for Heavy-Duty 2-Meter Machining

Product Overview
The MFG Machinery CK5120 is a formidable heavy-duty, single-column CNC Vertical Turning Lathe (VTL) engineered to conquer massive 2-meter class components.

Designed for the wind power, mining, aerospace, and heavy valve industries, this machine delivers uncompromising structural rigidity and extreme material removal rates.

At its core is a massive 30kW AC servo main motor paired with a robust 4-speed mechanical gearbox, providing stepless speed regulation and tremendous low-end torque for heavy roughing. Featuring a highly rigid square ram architecture and driven by the reliable GSK 980TDI CNC system (with Fanuc and Siemens options), the CK5120 ensures flawless precision when turning, boring, and facing your largest and most demanding workpieces.

Key Features & Advanced Engineering

• Massive 2-Meter Machining Capacity: Built upon an oversized, heavily ribbed cast-iron foundation, the single-column architecture provides exceptional stability when handling massive workpieces up to 2000mm in diameter, drastically expanding your shop's heavy-manufacturing capabilities.
• High-Rigidity Square Ram Structure: Engineered with a heavy-duty square ram design. This geometry maximizes bending stiffness, completely minimizes deflection, and provides superior vibration damping. It is the ultimate structural choice for high-precision deep-hole boring and aggressive interrupted cutting.
• 30kW Servo Drive with 4-Speed Transmission: The worktable is powered by a massive 30kW AC servo motor coupled with a 4-gear mechanical transmission. This allows for fully stepless speed regulation within each gear—delivering crushing torque for heavy raw-casting roughing, and incredibly smooth rotation for mirror-like finishing.
• Advanced & Customizable CNC Control: Comes standard with the highly reliable and user-friendly GSK 980TDI CNC system. For shops fully integrated into European or Japanese control ecosystems, premium Siemens and FANUC CNC controllers are readily available as optional upgrades.
• Flexible Automated Tooling: The standard configuration features a highly rigid manual tool post. To maximize automation and reduce cycle times, operators can seamlessly upgrade to an optional 4-station or 6-station vertical electric turret for rapid, precise tool indexing.
• Industrial Guarding & Eco-Management (Optional): To protect critical components and ensure a clean shop environment, the machine can be fully equipped with semi-enclosed splash guarding, stainless steel crossbeam covers, an automated chip conveyor, and a high-capacity coolant supply system.
