MFG Machinery CK5110 CNC Vertical Turning Lathe (VTL)

1000mm Capacity, 200x200mm Square Ram & 4-Speed Stepless Drive for Heavy Precision Turning

Product Overview
The MFG Machinery CK5110 is a highly versatile, heavy-duty single-column CNC Vertical Turning Lathe (VTL) engineered for exceptional precision and material removal rates.

Built to harness the full cutting potential of high-speed steel (HSS), cemented carbide, and advanced high-performance cutters, it effortlessly processes ferrous metals, non-ferrous alloys, and non-metallic materials.

Featuring a massive 200x200mm square ram, a 22kW servo main motor with a 4-speed stepless transmission, and an advanced rolling-guide supported worktable, the CK5110 guarantees uncompromising rigidity.

Whether you are executing aggressive roughing or ultra-precise finishing of internal/external cylinders, conical profiles, planes, grooving, or complex revolving curved surfaces, this machine delivers world-class manufacturing performance.

Key Features & Advanced Engineering

• Heavy-Duty Square Ram Architecture: The vertical ram features a massive 200x200 mm square cross-section. This robust structural geometry maximizes bending stiffness and completely minimizes deflection, giving the machine a distinct advantage when executing high-precision deep-hole boring and heavy interrupted cuts.
• Rolling Guide Supported Worktable: Unlike traditional high-friction sliding tracks, the CK5110 worktable base utilizes a high-precision rolling guide support system. This significantly reduces thermal distortion and rotational friction, allowing for higher table speeds, superior load capacities, and long-term precision retention.
• 22kW Servo Drive with 4-Speed Stepless Transmission: The main worktable is driven by a powerful 22kW servo motor paired with a 4-speed mechanical transmission. This allows for completely stepless speed regulation within each gear range—delivering massive cutting torque at low speeds for roughing, and incredibly smooth, vibration-free rotation at high speeds for fine finishing.
• Flexible Tooling Configurations: The machine can be customized to fit your exact production needs. Choose the standard high-rigidity tool post, or upgrade to an optional 4-station or 6-station electric turret for rapid, automated tool indexing and reduced cycle times.
• Advanced CNC Integration: Configurable with top-tier control systems, including the highly requested Siemens 828D CNC system (optional). This ensures seamless programming, advanced contouring capabilities, and highly reliable multi-axis synchronization.
• Semi-Enclosed Guarding & Eco-Management: Designed with a semi-enclosed splash guard to protect the operator and contain debris. The machine can be fully equipped with an optional automated chip conveyor and a high-capacity cooling water supply system to maximize tool life and maintain a clean shop environment.
